CNTD CE Approval Adjustable Roller type Elevator Limit Switch Omron Switch Replacement (CWLCA12-2-Q)

FOB Reference Price:Get Latest Price
US $4-7 / Pieces | 1 Piece/Pieces Sample is available for testing. (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
CNTD
Model Number:
CWLCA12-2-Q
Protection Level:
IP66
Operating Temperature:
-5~+65C (with no icing)
Max. Current:
10A
Max. Voltage:
250V
Type:
Limit switch
Contact Form:
NO, NC
Service Life:
Mechanical: above 10,000,000 times; Electrical: above 500,000 times
Shell Material:
strong aluminum cast
Selective Cable Gland:
M20x1.5
Single Weight:
approx.275g
Standard:
IEC standard
Humidity:
<95%RH
Ambient Temperature:
-10~80C
Certificate:
CE
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
50pcs in one carton (standard export packing);
N.W/G.W: 15KG / 16KG
Packing size: 45x29x24CM
Port
Ningbo/Shanghai Port, China
Lead Time :
In 3-7 working days after deposit confirmed




CNTD CE Approval Adjustable Roller type Elevator Limit Switch Omron Switch Replacement (CWLCA12-2-Q)



Features

  •  Double-circuit type of limit switch, widely used
  •  With strong aluminum cast outer shell
  •  High mechanical strength
  •  Water-proof, oil-proof construction
  •  Structure preventing oil, water and pressure
  •  Indicating plate with setting position is installed in it, so it is easy to maintain
  •  Various of actuators for option, easy to use
  •  Built-in contact stand has double-spring, so it has long mechanical life
  •  Selective M20 x 1.5 cable gland

Product Description

 Rating



Rated Voltage

Noninductive Load

(A)

Inductive Load

(A)

Resistance Load

Lamp Load

Inductive Load

Motor Load

NC

NO

NC

NO

NC

NO

NC

NO

125VAC

250VAC

480VAC

600VAC

10

5

3

1

3

2

1.5

1

1.5

1

0.8

0.5

10

5

3

1.5

5

3

1.5

1

2.0

1.0

0.8

0.5

8VDC

14VDC

30VDC

125VDC

250VDC

10

10

6

0.8

0.4

6

6

4

0.2

0.1

3

3

3

0.2

0.1

10

10

6

0.8

0.4

6

6

4

0.2

0.1







Characteristics



Operation speed

1mm-2m/sec

Operating frequency

Mechanical: 120 operations/minute, Electrical: 30 operations/minute

Contact resistance

15mΩ max. (initial value)

Insulation resistance

100mΩ min. (at 500VDC)

Dielectric strength

1000VAC, 50/60HZ for 1 minute between terminals of the same polarity



1500VAC, 50/60 HZ for 1 minute between currentcarrying

and non-current-carrying metal parts



1500VAC, 50/60 HZ for 1 minute between each terminal and ground

Vibration

10-55HZ,1.5mm double amplitude

Shock

Mechanical durable: 1, 000m/Sec2 (about 100G'S)

Malfunction: 300m/Sec2 (about 30G'S)

Ambient temperature

-10℃ to +80℃

Humidity

<95% RH

Life

Mechanical: 10,000,000 operations above

Electrical: 500,000 operations above

Weight

About 275g

Degree of protection

IP65



Appearance and Dimension
